SPARK: Coalesce VS Repartition

Spark splits data into partitions and executes computations on the partitions in parallel. You should understand how data is partitioned and when you need to manually adjust the partitioning to keep your Spark computations running efficiently.

Intro to partitions:

Lest’s create a DataFrame of numbers to illustrate how data is partitioned:

val x = (1 to 10).toList
val numbersDf = x.toDF(“number”)

On my machine, the numbersDf is split into four partitions:

numbersDf.rdd.partitions.size // => 4

Each partition is a separate CSV file when you write a DataFrame to disc.

numbersDf.write.csv(“C:\tmp\numberDFOutput”)

Here is how the data is separated on the different partitions. There would be four CSV files created in “C:\tmp\numberDFOutput” folder.

Partition A: 1, 2
Partition B: 3, 4, 5
Partition C: 6, 7
Partition D: 8, 9, 10

Intro to coalesce:

The coalesce method reduces the number of partitions in a DataFrame. Here’s how to consolidate the data in two partitions:

val numbersDf2 = numbersDf.coalesce(2)

We can verify coalesce has created a new DataFrame with only two partitions:

numbersDf2.rdd.partitions.size // => 2

numbersDf2 will be written out to disc as two text files:

numbersDf2.write.csv(“C:\tmp\numberDFOutput2”)

There would be 2 CSV files created in “C:\tmp\numberDFOutput2” folder. The partitions in numbersDf2 have the following data:

Partition A: 1, 2, 3, 4, 5
Partition C: 6, 7, 8, 9, 10

The coalesce algorithm moved the data from Partition B to Partition A and moved the data from Partition D to Partition C. The data in Partition A and Partition C does not move with the coalesce algorithm. This algorithm is fast in certain situations because it minimizes data movement.

Increasing partitions:

You can try to increase the number of partitions with coalesce, but it won’t work!

val numbersDf3 = numbersDf.coalesce(6)
numbersDf3.rdd.partitions.size // => 4

numbersDf3 keeps four partitions even though we attemped to create 6 partitions with coalesce(6).

The coalesce algorithm changes the number of nodes by moving data from some partitions to existing partitions. This algorithm obviously cannot increate the number of partitions.

repartition:

The repartition method can be used to either increase or decrease the number of partitions in a DataFrame.

Let’s create a homerDf from the numbersDf with two partitions.

val homerDf = numbersDf.repartition(2)
homerDf.rdd.partitions.size // => 2

Let’s examine the data on each partition in homerDf:

Partition ABC: 1, 3, 5, 6, 8, 10
Partition XYZ: 2, 4, 7, 9

Partition ABC contains data from Partition A, Partition B, Partition C, and Partition D. Partition XYZ also contains data from each original partition(i.e Partition A, Partition B, Partition C, and Partition D) . The repartition algorithm does a full data shuffle and equally distributes the data among the partitions. It does not attempt to minimize data movement like the coalesce algorithm.

Increasing partitions:

The repartition method can be used to increase the number of partitions as well.

val bartDf = numbersDf.repartition(6)
bartDf.rdd.partitions.size // => 6

Here’s how the data is split up amongst the partitions in the bartDf.

Partition 00000: 5, 7
Partition 00001: 1
Partition 00002: 2
Partition 00003: 8
Partition 00004: 3, 9
Partition 00005: 4, 6, 10

The repartition method does a full shuffle of the data, so the number of partitions can be increased.

Differences between coalesce and repartition:

The repartition algorithm does a full shuffle of the data and creates equal sized partitions of data. coalesce combines existing partitions to avoid a full shuffle. We can increase the number of partitions using REPARTITION while we cannot increase the number of partitions using COALESCE.

repartition by column:

Let’s use the following data to examine how a DataFrame can be repartitioned by a particular column.

+-----+-------+
| age | color |
+-----+-------+
|  10 | blue  |
|  13 | red   |
|  15 | blue  |
|  99 | red   |
|  67 | blue  |
+-----+-------+

We’ll start by creating the DataFrame:

val people = List(
  (10, "blue"),
  (13, "red"),
  (15, "blue"),
  (99, "red"),
  (67, "blue")
)
val peopleDf = people.toDF("age", "color")

Let’s repartition the DataFrame by the color column:

colorDf = peopleDf.repartition($"color")

When partitioning by a column, Spark will create a minimum of 200 partitions by default. This example will have two partitions with data and 198 empty partitions.

Partition 00091
13,red
99,red

Partition 00168
10,blue
15,blue
67,blue

// Other 198 Partitions are empty.

The colorDf contains different partitions for each color and is optimized for extracts by color. Partitioning by a column is similar to indexing a column in a relational database.

Real World Example:

Suppose you have a data lake that contains 2 billion rows of data (1TB) split in 13,000 partitions.

You’d like to create a sample data that’s a random sampling of one millionth of the data lake i.e you filtered the data lake and created a sample data which would contain one millionth of the data lake i.e around 2000 records. The sampled data will be used in development and the data lake will be reserved for production grade code. You’d like to write the data puddle out to S3 for easy access.

Here’s how you’d structure the code:

val sampledData = dataLake.filter({...})
sampledData.write.parquet("s3a://my_bucket/data/")

Spark doesn’t adjust the number of partitions when a large DataFrame is filtered, so the sampledData will also have 13,000 partitions. The sampledData only contains 2,000 rows of data, so a lot of the partitions will be empty. It’s not efficient to read or write thousands of empty text files to S3 — we should improve this code by repartitioning.

val sampledData = dataLake.filter({...})
val goodSample = sampledData.repartition(4)
goodSample.write.parquet("s3a://my_bucket/data/")

Why did we choose 4 partitions for the data puddle?

The data is a million times smaller, so we reduce the number of partitions by a million and keep the same amount of data per partition. 13,000 partitions / 1,000,000 = 1 partition (rounded up). We used 4 partitions so the sampled data can leverage the parallelism of Spark.

In general, you can determine the number of partitions by multiplying the number of CPUs in the cluster by 2, 3, or 4.

If you’re writing the data out to a file system, you can choose a partition size that will create reasonable sized files (100MB). Spark will optimize the number of partitions based on the number of clusters when the data is read.

Why did we use the repartition method instead of coalesce?

A full data shuffle is an expensive operation for large data sets, but our sampled data is only 2,000 rows. The repartition method returns equal sized text files, which are more efficient for downstream consumers.

Actual performance improvement:

It took 241 seconds to count the rows in the data puddle when the data wasn’t repartitioned (on a 5 node cluster). It only took 2 seconds to count the data puddle when the data was partitioned — that’s a 124x speed improvement!

Conclusion:

When filtering large DataFrames into smaller ones, you should almost always repartition the data.
